1. The Logistics Math: How Many Pallets Fit in a Truck?
In 2026, freight efficiency is calculated using the standard 48" x 40" GMA pallet. The number you can fit depends on your loading orientation:
The "Turned" Trap: While loading 30 pallets (sideways) sounds better, many 2026 refrigerated trucks ("reefers") have thicker insulation. They may not be a full 102 inches wide inside, meaning two 48-inch pallets side-by-side (96 inches total) leave zero room for error or pallet overhang.
2. Manual vs. Electric: Choosing Your Weapon
If you are moving more than three pallets a week, your choice of pallet truck (or "pallet jack") will determine the health of your back and your warehouse efficiency.
-
Manual Pallet Truck: The industry tank. Best for tight spaces and low-volume work.
-
2026 Gold Standard: The Crown PTH 50. It’s rugged, easy to maintain, and the parts are available in every corner of the country.
-
Pro Tip: If the handle feels "spongy" and won't lift, it’s usually an air lock. Hold the release lever and pump rapidly 10 times to bleed the line.
-
-
Electric Jack Pallet Truck (Walkie): Motorized for zero-fatigue movement.
-
2026 Gold Standard: Linde MT12 or Toyota Electric Walkie.
-
Caution: These are heavy. If you take one on a delivery truck, ensure your liftgate can handle the combined weight of the jack (~500 lbs) plus the pallet.
-
3. The 2026 Safety Protocol: Using a Jack on a Liftgate
Liftgates are the most dangerous zone in logistics. One "runaway" pallet can crush an operator or destroy $5,000 in inventory.
-
Lower the Forks: Never leave a pallet raised on the jack wheels while the liftgate is moving. Gravity will take it.
-
Handle Positioning: Keep the handle facing the truck (uphill). You want to be pulling the load toward the street, not pushing it toward the edge.
-
Center the Weight: Ensure the pallet is centered on the liftgate platform to prevent the hydraulics from tilting unevenly.
4. Maximizing ROI with Closo
Efficient loading is only half the battle; you need to know if what's on those pallets is worth the fuel.
-
Closo Demand Signals: Before you pay for a full truckload (26 pallets), use Closo to verify that the "high-demand" items on the manifest haven't peaked.
-
Closo 100% Free Crosslister: Once you unload that 26-pallet haul, the clock is ticking. Use the Crosslister to push individual items to eBay, Mercari, and Poshmark immediately. The faster you clear the floor, the sooner you can order the next truck.
What Is a Pallet Truck? (And Why You Need a Good One)
When people ask what is a pallet truck, they usually picture the simple manual tool found in the back of every grocery store. But for us, it is the most critical tool in the arsenal. A pallet truck (often called a pallet jack or pump truck) is a wheeled trolley designed to lift and transport pallets. The forks slide into the pallet, the handle pumps hydraulic fluid to raise the forks, and you pull.
Here's where it gets interesting... Not all jacks are created equal. There are manual pallet trucks (the classic "pump and pull") and electric jack pallet trucks (motorized). If you are moving three pallets a week, a manual one is fine. If you are moving 50 pallets a day, a manual jack will destroy your back by Tuesday.
Opinion Statement: I believe that anyone serious about reselling needs to own their own jack. Relying on the truck driver to have one is a gamble. Half the time, their jack is broken, or they "forgot it," and you are left staring at a 1,000 lb pallet on the tail of the truck with no way to move it.
Hand Pallet Truck vs. Electric: Choosing Your Weapon
If you are in the market for jack pallet trucks, you have two main paths.
1. The Manual Pallet Truck
-
The Pro: It never runs out of battery. It is cheap (usually $300-$500).
-
The Con: It requires physical force to start the momentum. If the floor isn't perfectly smooth concrete, you are in for a workout.
-
My Go-To: The Crown PTH 50. It is the tank of the industry. I have one from 2018 that still works perfectly despite being dropped off a dock (accidentally).
2. The Electric Pallet Truck (Walkie)
-
The Pro: You push a button, and it moves. It creates zero fatigue.
-
The Con: They are expensive ($2,000+) and heavy. If the battery dies, it becomes a 500 lb paperweight.
-
My Recommendation: The Toyota Electric Walkie. It is nimble enough for a box truck but strong enough for a warehouse.
Honest Failure: I bought a cheap "off-brand" electric jack from an online auction. It worked for two weeks. Then the battery charger port melted. I couldn't find replacement parts because the manual was in a language I couldn't identify. I ended up scrapping it.
-
Lesson: Buy major brands (Raymond, Crown, Toyota, Uline) where you can actually buy parts.
How to Use a Pallet Truck (Without Hurting Yourself)
It sounds simple, but I see people do it wrong constantly. Learning how to use a pallet truck correctly saves your inventory and your spine.
-
The Approach: Line up the forks perfectly straight with the pallet gaps. If you go in at an angle, you will split the wood on the bottom boards.
-
The Drop: Make sure the lever is in the "Neutral" position (middle) to move freely. Push the forks all the way in.
-
The Pump: Switch the lever to "Pump" (down). Use full, long strokes. Don't do tiny baby pumps; it wears out the seal.
-
The Move: Pull, don't push.
-
Physics Note: When you pull, the steer wheels lead, giving you control. When you push, you are fighting the pivot point, and if the load is heavy, it can jackknife and crush your ankles.
-
Parenthetical Aside: (I once saw a guy try to push a heavy pallet down a slight incline ramp. The momentum took over, the jack turned sideways, and the entire pallet of Gatorade tipped over. It was a sticky, expensive mess. Always keep the load uphill from you on a ramp.)
The Logistics Math: How Many Pallets Fit in a Truck?
This is the million-dollar question for every logistics manager and FBA seller: how many pallets fit in a truck? The answer depends entirely on the truck size and the loading pattern. Let's assume we are using the industry standard 40" x 48" GMA Pallet.
The 53-Foot Trailer (The Big Rig)
When asking how many pallets fit into a 53' trailer, you have two options. A standard 53' dry van is roughly 102 inches wide and 636 inches long.
Option A: Straight Loading (Lengthwise)
-
You load the pallets with the 48" side running the length of the truck.
-
Math: 636" / 48" = 13.25.
-
You can fit 13 rows.
-
Since the truck is wide enough for two pallets side-by-side (40" + 40" = 80", leaving plenty of room), you fit 2 wide.
-
Total: 13 rows x 2 = 26 Pallets.
Option B: Turned Loading (Sideways)
-
You turn the pallets so the 40" side runs the length.
-
Math: 636" / 40" = 15.9.
-
You can fit 15 rows.
-
However, the width becomes tight. 48" + 48" = 96". The truck is 102" wide. You only have 6 inches of clearance.
-
Total: 15 rows x 2 = 30 Pallets.
Now the tricky part... Many older trucks or refrigerated trucks ("reefers") have thicker walls. They might not be a full 102" wide inside. If you try to load "Turned" (30 pallets) in a reefer, they often won't fit side-by-side. You will get stuck. Always measure the width of the truck for pallets before you commit to the 30-pallet plan.
I use Closo Demand Signals to determine if it's worth paying for the extra "pinwheeled" space. If the demand for the product is high enough to justify the extra labor of specialized loading, we do it. If not, we stick to straight loading for speed.
How Many Pallets Fit on a Truck (Box Trucks & Smaller Rigs)?
Most resellers don't use 53' trailers. We use 26' box trucks (Penske/U-Haul). So, how many pallets fit on a truck of this size?
The 26-Foot Box Truck
-
Length: ~312 inches.
-
Straight Load (48" long): 312 / 48 = 6.5.
-
Result: 6 rows x 2 wide = 12 Pallets.
-
-
Turned Load (40" long): 312 / 40 = 7.8.
-
Result: 7 rows x 2 wide = 14 Pallets.
-
The 24-Foot Box Truck
-
Length: ~288 inches.
-
Straight Load: 288 / 48 = 6.
-
Result: 12 Pallets.
-
-
Turned Load: 288 / 40 = 7.2.
-
Result: 14 Pallets.
-
Opinion Statement: If you rent a consumer truck (U-Haul), be careful. The wheel wells often protrude into the cargo area, killing your floor space. You might think you can fit 12, but the wheel wells will block 2 spots. Always assume you lose 2 pallet spots in a consumer rental truck unless it has a flat floor deck.
"Pinwheeling": The Advanced Loading Technique
If you want to maximize how many 40x48 pallets fit in a 53 trailer, you use a technique called Pinwheeling. This is where you alternate the direction of the pallets to fit the width constraints.
-
One pallet is loaded Straight (40" wide).
-
The pallet next to it is loaded Turned (48" wide).
-
Total width = 88". This fits easily in almost any truck. This allows you to usually fit 28 pallets comfortably without scraping the walls.
Safety Protocols: How to Use Pallet Truck on a Liftgate
The most dangerous 60 seconds of my life involve liftgates. Moving a 1,500 lb pallet from the truck onto a 4-foot metal platform is terrifying.
The Protocol:
-
Center the Load: Never have the heavy side of the pallet hanging off the edge.
-
Jack Position: Keep the jack handle facing the truck (uphill). You want to be between the truck and the pallet, not hanging off the edge of the liftgate.
-
The Drop: Lower the pallet onto the liftgate metal. Do not leave it raised on the jack wheels. If the liftgate tilts, the jack will roll off, taking the freight (and you) with it.
My Anecdote: I hired a driver who left a pallet of water bottles raised on his electric jack on the liftgate. He hit the "Lower" switch. The liftgate tilted down slightly. The electric jack rolled right off the back. It smashed onto the pavement. The jack survived (barely), but the pallet exploded.
-
Lesson: Always drop the forks to the ground before moving the liftgate.
Sourcing and Managing Inventory with Closo
You have the truck for pallets, you have the jack, and you know the math. But moving empty pallets is a waste of money. You need the inventory. I use Closo Wholesale to find manifested pallet lots that are worth the shipping cost.
The Workflow:
-
Source: I find a lot on Closo.
-
Analyze: I use Closo Demand Signals to check the velocity of the items.
-
Transport: I calculate the truck space. (Is it 12 pallets? Okay, I need a 26' truck).
-
Process: Once unloaded, I use the Closo 100% Free Crosslister to list the items.
I use Closo to automate the inventory breakdown – saves me about 3 hours weekly of manually typing data from the packing slip into eBay.
Common Failures with Jack Pallet Trucks
Even the best pallet trucks fail if you abuse them. 1. The "Choked" Wheel: Shrink wrap is the enemy. If you run over loose plastic wrap, it wraps around the wheel axle. Eventually, the wheel seizes.
-
Fix: Carry a box cutter. Check your wheels every week. 2. The Air Lock: Sometimes you pump the handle and nothing happens. There is air in the hydraulic line.
-
Fix: Hold the release lever down and pump the handle rapidly 10 times. This bleeds the air.
Parenthetical Aside: (I once thought my jack was broken and bought a new one. An old warehouse guy saw my "broken" jack, bled the air in 10 seconds, and it worked perfectly. I felt like an idiot. Try bleeding the line before you buy a new one.)
People always ask me...
How much weight can a manual pallet truck lift?
Common question I see. A standard manual pallet truck (like the Global Industrial or Uline models) is rated for 5,500 lbs. This is huge. However, actually pulling 5,500 lbs requires massive human strength. Practically, if the pallet is over 2,500 lbs, you want an electric jack.
Can I use a pallet truck on gravel or dirt?
Common question I see. No. Absolutely not. The small polyurethane wheels will sink instantly. If you need to move pallets on dirt, you need a "Rough Terrain Pallet Jack" (the ones with big pneumatic tires). Using a standard jack on asphalt is hard enough; gravel is impossible.
Conclusion
Mastering the use of pallet trucks and understanding how many pallets fit in a truck separates the amateurs from the professionals. It is the difference between a smooth delivery and a disaster on the loading dock. Don't cheap out on your equipment. Buy a good Crown or Toyota jack. Measure your truck width. And never, ever try to stop a moving heavy pallet with your body.
Get the logistics right, and the profit margin will protect itself. Use Closo Demand Signals to make sure the pallets you are moving are actually worth the sweat.
Start cross-listing with Closo today—because once you unload those 26 pallets, you're going to need to sell them fast.
